Wallbox

Since established, Shanghai Hengyi Mechanical and Electrical Engineering Co., Ltd. has placed a great deal of emphasis on new product development.EV charger, which is recently developed by us, will be officially sold at very competitive prices. We offer buyer Wallbox 11KW 3*16A Ev Charger Type 2 Three-Phase Fast Electric Vehicle Charging Station Unit that they need at prices that fit their pocket. The launch of a product that perfectly solves the industry's pain points is that Shanghai Hengyi Mechanical and Electrical Engineering Co., Ltd. has always adhered to the goal of technological innovation, and the newly developed products perfectly solve the pain points that have been lingering in the industry for a long time. Once launched, they have been enthusiastically sought after by the market.

Type:electric vehicle charging stationsModel:330E, NiroPlugInHybrid, Niro PHEV, Niro Short Range EV, Zoe, model3, MODEL S, Model X, XC40, 500
Year:2018-2019, 2012-2016, 2015-2016, 2017-2019, 2017-2019, 2015-2016, 2013-2016, 2018-2019, 2019-2019, 2017-2019, 2016-2018, 2008-2010, 2008-2012, 2018-2019, 2017-2019, 2018-, 2018-Function:APP Control, screen display, RFID, EV charging
Car Fitment:Renault, Fiat - Europe, VOLVO, Kia, bmw, TESLACharging Port:1port
Connection:Type 2, Type 1, GB/TWarranty:12 Months
Place of Origin:Shanghai, ChinaBrand Name:Hengyi
Model Number:SETX-1-22-7-AC-02-EUUse:Standard Battery, electric car
Output power:7KWIP Grade:IP55
Operating Current:32AOperating Voltage:220V ±20%
Charging Standard:SAE J1772/IEC 62196 OptionalService:3S(small qty, special, short time)
Certificate:CE TUVConnector:Copper Alloy , Ag plated

Product Description
Parameters
Model
SETX-1-38-11-AC-03-EU-W-S





Structure Appearance
product properties
Offline has screen
Dimension
370(H) × 220(W) × 85(D)mm
User Interface
4.3 inch display touch screen with Indicator light
Installation method
Wall-mounted / Free-standing  Installation
Wiring method
Bottom enter&out
Cable length
3.5m/5m/10m optional
Weight
8.0kg (Including charging gun)





Electrical Specification
Input voltage
AC400V±10%
Frequency
45-65Hz
Power rating
11KW
Measurement accuracy
OBM 1.0
Output voltage
AC400V±10%
Output current
3 × 16A
Standby power
5W


Function
Indicator light
Yes
Display
YES
RFID
Yes


Protection
Design standard
EN/IEC 61851-1 (2010 / 2017),EN/IEC 61851-22 (2001),EN/IEC 62196-1 (2014),EN/IEC 62196-2 (2017),ROHS directive 2011 /65/EU
Protection
Overvoltage protection, undervoltage protection, overload protection, short circuit protection, ground protection, over temperature protection, lightning protection, onboard A-type leakage protection






Operating Environment
Working temperature
-40-+65℃
Working Humidity
5%-95% no condensation
Working altitude
≤3000m
IP grade
≥IP55
Cooling mode
Natural cooling
Applicable
Indoor/Outdoor,No conductive dust, no corrosive gas, no explosive gas, no strong vibration
Special protection
UV resistance
MTBF
≥100000H
Optional
Installation components
□Stand pillar
Company Profile
Hengyi Mechanical&Electrical Engineering is an enterprise specializing in Research & Development of Electric Vehicle Charging products. The company has a strong R&D team and the team director conducted a visiting scholar study at the University of Michigan Dearborn from 2011 to 2012. And the company also has a complete production supporting system integrating mold design, manufacturing and injection molding. We can provide customized services to meet different needs from customers, in addition to our regular standard products. We constantly strive to provide each customer with better products along with customized services. We are committed to become the most professional and efficient manufacturer in the field of EV charging. Now our products adapt to vast majority of vehical models around the world and we will continously update to provide with safe and efficient EV charging products.
FAQ
Q1:How do you package it ?
A:We pack in cartons.

Q2:what's the MOQ?
A:For LOGO, color or other special requirements, a minimum of 20 is required. If you do not have these requirements you can buy directly, we will ship within 3-10 days.

Q3:Can you produce according to the samples?
A:Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q4:Do you test all your goods before delivery?
A:Yes, we have 100% test before delivery.

Q5:What is your terms of delivery?
A:EXW, FOB, CFR, CIF, DDU.

Q6:What is your terms of payment?
A:We accept all methods of payment: paypal, T/T, credit card, assurance, West Union... Please contact us for more details.
